D2953M

Output Power 輸出功率: 10W~60W

Weight 重量: 160g (Approx.)

DC Motor - Typical Application 直流電機 - 典型應用

With Hall PCBA

含霍爾接線板

Automotive Parts: Tailgate Lear Actuator.

汽車部件：尾門撐桿

Model

型號

(DC Motor直流馬達)

Voltage(V) 電壓

No Load 空載

Rated Load 額定負載

Stall 堵轉

Operating Range

Rated

Speed (rpm)

Current (A)

Torque (mNm)

Speed (rpm)

Current (A)

Output P. (W)

Torque (mNm)

Current (A)

D2953M-S01

9~16

12

8050

0.78

50

6750

3.8

35

309

19

Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

注意：上述規格僅針對特定客戶，電壓、扭矩、轉速、電流、功率、輸出軸的特征和尺寸等都可以按照客戶的特殊要求進行調整。
